DTECH is specialized in Audio & Video & IOT converter R&D, manufacture and sales, which integrates R&D department, ODM department and a strong sales network. Main business: HDMI Extender Splitter,HDMI Cable,HDMI Fiber Cable,USB Cable,Type C Cable,USB Serial cable,RS232 RS422 RS485 Cable,Industrial converter etc.
-
-
-
-
TX RX HDMI Extender 1080P 150M HDMI Audio Video Wireless Extender Transmitter and Receiver
TX RX HDMI Extender 1080P 150M HDMI Audio Video Wireless Extender Transmitter and Receiver
Ⅰ.Product Parameters
Product Name
150M HDMI Wireless Extender
HDMI Resolution
Up to 1920x1080p/60Hz
Support Audio Format
Stereo audio
Max Bandwidth
148.5MHz
Transmitter Max Working Current
450mA
Receiver Max Working Current
320mA
Warranty
1 Year
This HDMI Wireless extender uses 5G modules to enable high-speed, high performance wireless communication among consumer electronics, computer and mobile devices. It combines high bandwidth capacity and strong error correction capability, to transmit HD video. It transmit the signal up to 150m in the open area, also go through the wall.
Features:
* Support HDCP1.3; * Support standard IEEE802.11a/n; * Support the highest rate 1.485G and TMDS clock up to 148.5Mhz; * Working in 5G frequency band,not easy disturbed to wireless signals; * The longest distance can be 150m when open space without any barriers, normal go through the wall up to 40 meters.
Ⅱ.Product Image
-
DT-HDWX001 4K 30Hz KVM Hdmi USB Extender Video Wireless Transmitter and Receiver 100 Meter
DT-HDWX001 4K 30Hz KVM Hdmi USB Extender Video Wireless Transmitter and Receiver 100 Meter
Ⅰ.Product Parameters
Product Name
KVM HDMI Wireless Extender 100M
Wireless Standard
802.11 ac WiFi MIMO technology
Wireless Band
4.900 GHz ~ 5.845 GHz (5GHz ISM Band)
Antenna Type
External dual 5dBi gain antenna
Resolution
4K/30Hz
Transmission Distance
≤100m (in open space)
Warranty
1 Year
1. HDMI signal supports 4K@30HZ ard is backward compatible with multiple resolutions.
2. Support RS232 remote transmission function.
3. Support USB keyboard and mouse remote control, IR infrared remote control function.
4. Support one sender to one receiver, one sender to four receivers, four senders to one receiver, three transmission methods.
5. HDMI supports local loop-out, the resolution follows the signal source, and there is no delay.
6. Support AUX analog audio input or HDMI synchronous output analog audio signal, connect external headphones or power amplifier equipment.
Ⅱ.Product Image
Ⅲ.Interface Definition
Ⅳ.Connection Diagram
-
DTECH DT-7054A(AM) 1080P Network Cable Extender with IR Transmitter Receiver 150m HDMI USB KVM Extender
DTECH DT-7054A(AM) 1080P Network Cable Extender with IR Transmitter Receiver 150m HDMI USB KVM Extender
Ⅰ.Product Parameters
Product Name
HDMI IR KVM Extender 150M
Model
DT-7054A(AM)
Resolution
HDMI signal support 1080@60Hz resolution, downward compatible with a variety of resolutions
Transmission Distance
Support one-to-one long-distance audio and video transmission of 150 meters
Feature
Support KVM, and can remotely control the device using a USB 1.1 keyboard and mouse
Power Supply
DC 5V
Material
Metal
Warranty
1 Year
Ⅱ.Product Descriptions
This high-definition extender consists of a transmitter and a receiver. It can transmit HDMI audio and video signals over long distances through Category 5e and Category 6 network cables, with an extended distance of up to 150 meters. This product is widely used in computer teaching systems, high-quality multimedia displays, video conferencing, computers, digital home theaters, exhibitions, education, finance, scientific research, meteorology and other fields.
-
1080P Full HD Audio Video Wireless HDMI Transmitter and Receiver Extender 200m
1080P Full HD Audio Video Wireless HDMI Transmitter and Receiver Extender 200m
Ⅰ.Product Parameters
Product Name
Wireless HDMI Extender
Model
DT-YZ-F007-2
Power Supply
DC 12V
Transmission Distance
200m
Resolution
1080P
Material
Metal Shell
Warranty
1 Year
Ⅱ.Product Description
HDMI extender with a standard Ethernet TCP/IP protocol, through wireless WIFI signal transmission HD audio and video signal, which can realize the one-to-many application, at the same time, with infrared extensions to make remote control more convenient.The equipment has excellent image processing and transmission capacity, makes signal transmission more smooth and steady, is a kind of economic and efficient way of HDMI signal extension.
-
-
-
-
DTECH 1080P HDMI RS232 IR Function Fiber Video Extender 20km 4K 60Hz with KVM
DTECH 1080P HDMI RS232 IR Function Fiber Video Extender 20km 4K 60Hz with KVM
Ⅰ. Product Parameters
Product Name
Fiber Extender with KVM
Brand
DTECH
HDMI Version
4K@60Hz / HDCP2.2
HDMI Resolution
The highest input resolution is 3840*2160@60Hz
Audio Format
L-PCM
Fiber Wavelength
1310nm; 1550nm
Fiber Transmission Distance
20km
The Maximum Operating Current
1.5A/5V DC(TX), 1.2A/5V DC (RX)
Operating Temperature Range
-10℃~+55℃
WDimension (L x W x H)
106x106x17(mm)
Weight
TX:272.1g RX:273.1g
Ⅱ. Product Introduction
HDMI fiber extender is a device transmitting HD audio and video signal via bidirectional single fiber cable. It transmits your HD display with the high resolutions up to 20km. It support IR, RS232 and KVM function.By using bidirectional single fiber LC interface, it has the characteristics of low cost and stable signal transmission. It can be used in security monitoring, high-definition signals between buildings, square large screens and other long-distance HDMI signal transmission fields.
Ⅲ. Product Features
*Support HDMI 4K@60Hz/HDCP2.2;
* Support transmitter HDMI Loop out;
* Support 3.5mm stereo output;
* Support IR;
* Support KVM;
* Support RS232;
* Comply with SFP MSA and SFF-8472 standard protocol;
* Pure hardware design, plug and play, do not need to install additional software;
* Support 4K to 1080P resolution (Downscaling).
Ⅳ. Product List
1: HDMI fiber extender transmitter 1PC
2: HDMI fiber extender receiver 1PC
3: DC 5V/2A power supply 2PCS
4: User manual 1PC
5: IR Cable 1PAIR
-
DTECH 4K HDMI Extender via Ethernet Video Transmitter Receiver Converter HDMI Cable Cascading Extender
This HDMI cascading extender uses a CAT 5e/6e cable to extend the HD signal up to 50 meters, and can reach 4K. It can be extended through the multi-level connection of the receiving end, and it can also realize a transmitter, and multiple receivers do not need to go through the switch. Concatenated cascade transmission (up to 5 receivers). It is widely used in computer teaching systems, high-quality multimedia displays, video conferences, computers, LCD plasma high-definition display venues, digital home theaters, exhibitions, education, finance, scientific research, meteorology and other fields.
-
-
DTECH Transmitter and Receiver Fiber Extender with HDMI/KVM Extender over Fiber 20KM 4K@60HZ
DTECH Transmitter and Receiver Fiber Extender with HDMI/KVM Extender over Fiber 20KM 4K@60HZ
Ⅰ. Product Parameters
Product Name
Fiber Extender with KVM
Brand
DTECH
HDMI Version
4K@60Hz / HDCP2.2
HDMI Resolution
The highest input resolution is 3840*2160@60Hz
Audio Format
L-PCM
Fiber Wavelength
1310nm; 1550nm
Fiber Transmission Distance
20km
The Maximum Operating Current
1.5A/5V DC(TX), 1.2A/5V DC (RX)
Operating Temperature Range
-10℃~+55℃
WDimension (L x W x H)
106x106x17(mm)
Weight
TX:272.1g RX:273.1g
Ⅱ. Product Introduction
HDMI fiber extender is a device transmitting HD audio and video signal via bidirectional single fiber cable. It transmits your HD display with the high resolutions up to 20km. It support IR, RS232 and KVM function.By using bidirectional single fiber LC interface, it has the characteristics of low cost and stable signal transmission. It can be used in security monitoring, high-definition signals between buildings, square large screens and other long-distance HDMI signal transmission fields.
Ⅲ. Product Features
*Support HDMI 4K@60Hz/HDCP2.2;
* Support transmitter HDMI Loop out;
* Support 3.5mm stereo output;
* Support IR;
* Support KVM;
* Support RS232;
* Comply with SFP MSA and SFF-8472 standard protocol;
* Pure hardware design, plug and play, do not need to install additional software;
* Support 4K to 1080P resolution (Downscaling).
Ⅳ. Product List
1: HDMI fiber extender transmitter 1PC
2: HDMI fiber extender receiver 1PC
3: DC 5V/2A power supply 2PCS
4: User manual 1PC
5: IR Cable 1PAIR
-
-
