USB 3.0 4Port High Speed Expansion Hub 5Gbps DC 5V/2.4A fast charge usb hub for cell phone/pad/MP3/4

New Products

USB 3.0 4Port High Speed Expansion Hub 5Gbps DC 5V/2.4A fast charge usb hub for cell phone/pad/MP3/4

USB 3.0 4Port High Speed Expansion Hub 5Gbps DC 5V/2.4A fast charge usb hub for cell phone/pad/MP3/4

  • Product Origin:

    china
  • Brand:

    DTECH
  • Item NO.:

    dt-3309
  • Shipping Port:

    guangzhou/shenzhen
Product Details

It supports BC1.2 charging function, charging current of each port can be 2.4A maximum. With off-line charging function, no need connect computer. It can become a multi-port charger when connected with a USB power adapter, can charge for cell phone/pad and other digital devices.

1. Adopts GL3525 original chip with high performance and low power consumption. Can rapidly expand 4 independent port hub for computer and laptop. It will make USB3.0 transmission more stable when connect to U disk, keyboard, mouse, mobile HD etc.

2. Equipped with micro USB charging port, can supply power for super power devices, no need to equip DC charger, more convenient than DC charging.

3. Supports off-line charging, supports 2.4A fast charge.

4. With LED indicator, more convenient to use.

5. Adopts safe data circuit protection design, with built-in over current, over-voltage, electric leakage protection module.

6. The cable use multi-layer weave, pure copper shielding technology, effectively resist to electromagnetic interference.

7. Electrostatic discharge voltage protection: ±8KV

8. Working temperature

  40-50(ambient temperature 20)

9. Electrical specification

   Rated input voltage: DC 5V  Input current: external power supply 1000mA~4000mA

          10. Product specification: 59.35mm*59mm Net weight:45g
