This extender supports 1080P@60Hz resolution and backward compatible; it supports IR infrared return, allowing users to control the device remotely ; using the CAT5e/6 cable can be extended to 120 meters, can realize cascading transmission via switch or router. After a series of tests, the following results are obtained.
Product Origin:
chinaBrand:
DTECHItem NO.:
dt-7043Shipping Port:
guangzhou/shenzhen
1. Product description
This HDMI IP extender supports 1080P@60Hz resolution. The product extends the audio video signals to the far end through the LAN cable, and the transmission distance up to 120 meters. More than 120 meters can be extended by the switch multi-level connection, one transmitter can connect to many receivers (up to 253 receivers). At the same time, it is convenient to use point-to-point, point-to-multipoint, cascading connection to transmit HDMI signals. It can be widely used in computer teaching systems, high-quality multimedia display, video conferencing, computer, LCD plasma high-definition display venues, digital home theater, exhibitions, education, finance, scientific research, meteorology and other fields.
2. Product function parameters
(1) Adopt broadcast-level bandwidth balanced transmission mode, which has strong anti-interference ability, and can be extended to 120 meters by using Cat6e network cable;
(2) Support Cat5e/Cat6e/single shielded/unshielded twisted pair real-time point-to-point, point-to-multipoint transmission of image and audio signals;
(3) HDMI signal supports 1080P@60Hz resolution, backward compatible with multiple resolutions;
(5) Support IR infrared return function;
(6) It has a signal 3dB gain or pre-compensation to ensure high-resolution true restoration of the signal;
(7) Lightning protection, dustproof, anti-static, and prolong the service life;
(8) It can be cascaded and amplified by relay devices such as switches/routers to achieve an extension of 240 meters.
3. Product operating temperature
(1) transmitter working temperature: 40 ° C -75 ° C (room temperature 25 ° C)
(2) Receiver working temperature: 40 ° C -75 ° C (room temperature 25 ° C)
4. Notes
(1) Using the switch to transmit, the video signal can be sent over and over again.
(2) Please use this product at the allowable distance, 120 meters via CAT5e/CAT6 cable.
5. Electrical specifications
Rated input voltage: DC 5V
Input current: external power supply 1000mA
6. Volume and weight
(1) Product volume:
Transmitter: 105mm*75mm*25mm
Receiver: 105mm*75mm*25mm
(2) Product weight: g ± 10g
